Default Propeller Performance: F/P vs C/S

Anybody have any performance comparison numbers switching from the Sensenich F/P propeller to a C/S prop on their RV-9 or -9A? My project, RV-9A, came with the Sensenich F/P prop, but the engine, Mattituck IO-320, is capable of C/S by removing the CS plug and adding a governor. I know the benefits of a C/S prop but just trying to figure out if I want to make the switch while the F/P prop is still new in the box. I would love some before and after the swap performance numbers to help me justify the added costs. Thanks! Dave
__________________
David C.
Howell, MI

RV-9A: Under Construction
RV-10: N959RV Completed 12/29/2013 SOLD 08/23/2016

"Donor Exempt" but donated through Dec. 2017
Reply With Quote
  #2
Old 06-27-2017, 08:24 AM
MS19087's Avatar
MS19087 MS19087 is offline

Join Date: Nov 2006
Location: PA
Posts: 520
Default Check you PMs

Then give me a call . . .
__________________
Mark
RV-9A; IO-320 w/ Whirlwind WW-151
(Flying since June 2011)
2017 =VAF= donor
Reply With Quote
  #3
Old 06-27-2017, 09:49 AM
Lars Lars is offline

Join Date: Nov 2005
Location: Davis, CA
Posts: 916
Default

Watch the weight on the nosewheel.

I just finished an RV-9A for a friend. Vertical draft IO-320, Catto 3 blade prop. It does have a backup alternator and mufflers on the exhaust, but otherwise it's not an exceptionally equipped (read: heavy) airplane.

After weighing I was surprised to discover that, while it would be in the CG range for all conceivable loading conditions, the allowable weight on the nosewheel would be exceeded with more than 3/4 fuel unless at least 30 pounds was carried in the baggage compartment. Lighter passengers/pilots requiring more weight.

More info here: http://www.vansaircraft.com/pdf/Nose...ice_letter.pdf

Likely paint will move the CG far enough aft that it will cease to be a problem, but meanwhile I have 6 pounds of lead under the empennage fairing.

Point being that there is no way this airplane could be safely equipped with a constant speed prop without a serious diet forward of the current empty CG.
__________________
Lars Pedersen
Davis, CA
RV-7 Flying as of June 24, 2012
Reply With Quote
  #4
Old 06-27-2017, 12:00 PM
airguy's Avatar
airguy airguy is offline

Join Date: Oct 2006
Location: Garden City, Tx
Posts: 3,800
Default

Quote:
Originally Posted by Lars View Post
Point being that there is no way this airplane could be safely equipped with a constant speed prop without a serious diet forward of the current empty CG.
Move the battery aft of the baggage compartment rear wall, and most of the CG shift that you'll need is accomplished.
__________________
Greg Niehues - VAF 2017 dues paid
Garden City, TX
N16GN flying! http://websites.expercraft.com/airguy/
Built an off-plan 9A with too much fuel and too much HP. Should drop dead any minute now.
Reply With Quote
  #5
Old 06-27-2017, 01:05 PM
N941WR's Avatar
N941WR N941WR is offline

Join Date: Jan 2005
Location: SC
Posts: 10,921
Default

Will using a composite CS prop solve the nose wheel weight issue?
__________________
Bill R.
RV-9 (Yes, it's a dragon tail)
O-360 w/ dual P-mags
Build the plane you want, not the plane others want you to build!
SC86 - Easley, SC
www.repucci.com/bill/baf.html
Reply With Quote
  #6
Old 06-27-2017, 01:17 PM
N941WR's Avatar
N941WR N941WR is offline

Join Date: Jan 2005
Location: SC
Posts: 10,921
Default

As for performance numbers, I have never flown my -9 with a CS prop but have flown it with two different engines and FP props.

The only advantage the CS prop gives you is on takeoff acceleration. Cruise speeds can be identical, with often the advantage going to the FP prop. However, to do that, you have to spin your FP prop on the redline, which the engine is designed to do.

If the cost is an issue, you can always install one later.
__________________
Bill R.
RV-9 (Yes, it's a dragon tail)
O-360 w/ dual P-mags
Build the plane you want, not the plane others want you to build!
SC86 - Easley, SC
www.repucci.com/bill/baf.html
Reply With Quote
  #7
Old 06-27-2017, 01:39 PM
RV6_flyer's Avatar
RV6_flyer RV6_flyer is offline

Join Date: Jan 2005
Location: Uniontown, PA
Posts: 2,700
Default Kitplanes July 2016 Wind Tunnel

Read the Fixed pitch vs. constant speed article in "Wind Tunnel"column from the July 2016 issue of Kitplanes.

I believe that you must be a subscriber to Kitplanes to read the article or any back issue.
__________________
Gary A. Sobek
KVVS RV-6
Flying
3,300+ hours
Building RV-8 S/N: 80012

To most people, the sky is the limit.
To those who love aviation, the sky is home.

Last edited by RV6_flyer : 06-27-2017 at 02:51 PM.
Reply With Quote
  #8
Old 06-27-2017, 01:57 PM
rvsxer rvsxer is offline

Join Date: May 2007
Location: Inver Grove Hgts, MN
Posts: 219
Default

Quote:
Originally Posted by RV6_flyer View Post
Read the Fixed pitch vs. constant speed article in "Wind Tunnel"column from the July 2016 issue of Kitplanes.

I believe that you must be a subscriber to Kitplanes to read the article or any back issue.
Try this link...
http://www.kitplanes.com/issues/33_7...d_21591-1.html
__________________
Mike Hilger
RV-6 N207AM w/G3X, 1,400 hours +
South St. Paul, MN (KSGS)
Senior Tech - Panel Design, SteinAir, Inc.
A&P, EAA Tech Counselor

We're all here because we're not all there...
Reply With Quote
  #9
Old 06-27-2017, 03:22 PM
Steve Melton's Avatar
Steve Melton Steve Melton is offline

Join Date: Apr 2011
Location: Cincinnati, OH
Posts: 1,240
Default

I have WW200 and a big 25lb battery. I carry some tools, a fly away parts kit and a fireX in the baggage . it's been good.

Empty Weight with oil included, no paint, with anti-splat nose brace and lip skid, firewall insulated with 1" ceramic fibre
Left 389.5 lb
Nose 280.8 lb
Right 411.5 lb

Total 1081.8 lb

__________________
Steve Melton
Cincinnati, OH
RV-9A, Tip-up, Superior O-320, roller lifters, 160HP, WW 200RV, dual impulse slick mags, oil pressure = 65 psi, EGT = 1300F, flight hours = 600+ for all

Simplicity is the art in design.

Last edited by Steve Melton : 06-27-2017 at 03:30 PM.
Reply With Quote
  #10
Old 06-27-2017, 04:06 PM
Steve Koziol Steve Koziol is offline

Join Date: Sep 2011
Location: Doylestown, PA
Posts: 36
Default

I haven't flown behind a Sensenich FP but I have over 700 hrs on a 3 blade Catto. Some specs on my airplane.
Total weight 1084 lbs
Right Main 395lbs
Left Main 394lbs
Nose Wheel 295lbs

AeroSport Power O320 D2A, roller tappets, dual Slick Mags, and a backup alternator where the vacuum pump would be attached on the rear of the engine. Climb performance at 100-110 knots is about 1200 to 1300 fpm at moderate weight. (1550lbs or so).

For me, the climb performance and cruise speeds are far better than anything that I flew in the past. I didn't see the need to drop another 8-10K for the prop and governor for what I felt was a minimal increase in performance. Just my thoughts. Good luck on your search.

Steve Koziol
