Default RV-10 Emp Antennas and Static Wicks

Hello VAF,

After significant deliberation and thought I purchased RV-10 empennage/tailcone kit #41863 from Vans! I took a demo flight in one at SNF and we have a mission that the -10 fits perfectly so took the leap and ordered the emp kit. Quickly after its arrival I found out that decisions need to be made rather quickly as going back will take significant effort later to add or change things. I have been researching antennas and would like to place a VOR antenna in the top of the tail for VOR/LOC/GS as it seems cat whiskers have the best reception and reliability performance. I have seen pictures of others who have done this and would like to know if there is a specific model of antenna that installs the best or performs better than others? Even within the Comant line they vary wildly in price and I cannot seem to find a reason why?

Additionally I was wondering if static wicks are necessary or above and beyond? Thanks
Reply With Quote
  #2
Old 01-17-2018, 10:40 PM
BobTurner BobTurner is offline

Join Date: Dec 2011
Location: Livermore, CA
Posts: 5,199
Default

Not what you asked, but Iíd say skip the cat whisker. Put in an ĎArcherí wingtip antenna. Gain 1/4 knot, keep from poking out your eye.
Most people seem to be skipping static wicks, too.
Reply With Quote
  #3
Old 01-18-2018, 05:10 AM
vic syracuse vic syracuse is offline
Super Moderator

Join Date: May 2005
Location: Locust Grove, GA
Posts: 2,295
Default

I put the VOR antenna underneath the tail just ahead of the tie down. Can receive VOR's 90 miles out at altitude, and no issues when intercepting Localizer from left or right.

Vic
__________________
Vic Syracuse

Built RV-4, RV-6, 2-RV-10's, RV-7A, RV-8, Prescott Pusher, Kitfox Model II, Kitfox Speedster, Kitfox 7 Super Sport, Just Superstol, DAR, A&P/IA, EAA Tech Counselor/Flight Advisor, CFII-ASMEL/ASES
EAA Homebuilt Council Chair/member EAA BOD
Van's East Coast Representative
www.Baselegaviation.com
Reply With Quote
  #4
Old 01-18-2018, 07:24 AM
Carl Froehlich's Avatar
Carl Froehlich Carl Froehlich is offline

Join Date: Dec 2007
Location: Dogwood Airpark (VA42)
Posts: 1,536
Default

Quote:
Originally Posted by vic syracuse View Post
I put the VOR antenna underneath the tail just ahead of the tie down. Can receive VOR's 90 miles out at altitude, and no issues when intercepting Localizer from left or right.

Vic
Iíve seen this on a few RV-10 and it just scares me to think of the owner or some kid bending down under the tail and leaving an eyeball on one of these antenna rods.

I know - Iím just a worry wart.

Considering my homemade wingtip VOR antenna picks up VORs at 100+nmi and LOC/IOLS way beyond practical range, I can think of no reason to have any VOR antenna out in the breeze. Overlay that with the other practical aspect of five years of IFR cross country flying in the RV-10 and never using a VOR - other than tuning in the next one down the track ďjust in caseĒ.

Carl
Reply With Quote
  #5
Old 01-18-2018, 07:40 AM
9GT's Avatar
9GT 9GT is offline

Join Date: Jan 2010
Location: Southern Michigan
Posts: 1,443
Default

I put mine up there. Keeps it out of the way and gets great reception. I know some people put it on the bottom of the tail cone, but I do not like the look of them there. I can't remember the brand I used but the whiskers went into a composite puck about 2-1/2" - 3" diameter and 5/8" thick. I had to trim the top of the VS fairing to fit it in. After installation I faired it in with some micro & flox mix and painted what stuck out after masking off the rods.
[IMG]DSC01478 by David C, on Flickr[/IMG]
__________________
David C.
Howell, MI

RV-9A: Under Construction. N161RV (Reserved)
RV-10: N959RV Completed 12/29/2013 SOLD 08/23/2016

"Donor Exempt" but donated through Dec. 2018
Reply With Quote
  #6
Old 01-18-2018, 07:44 AM
9GT's Avatar
9GT 9GT is offline

Join Date: Jan 2010
Location: Southern Michigan
Posts: 1,443
Default

Quote:
Originally Posted by Carl Froehlich View Post
Iíve seen this on a few RV-10 and it just scares me to think of the owner or some kid bending down under the tail and leaving an eyeball on one of these antenna rods.

I know - Iím just a worry wart.

Considering my homemade wingtip VOR antenna picks up VORs at 100+nmi and LOC/IOLS way beyond practical range, I can think of no reason to have any VOR antenna out in the breeze. Overlay that with the other practical aspect of five years of IFR cross country flying in the RV-10 and never using a VOR - other than tuning in the next one down the track ďjust in caseĒ.

Carl
I am considering the Archer wing-tip VOR antenna in my -9 Carl. Do you know if LED lighting and strobes give any interference with the Archer since its all in the same space in close proximity to each other?
__________________
David C.
Howell, MI

RV-9A: Under Construction. N161RV (Reserved)
RV-10: N959RV Completed 12/29/2013 SOLD 08/23/2016

"Donor Exempt" but donated through Dec. 2018
Reply With Quote
  #7
Old 01-18-2018, 07:54 AM
Auburntsts's Avatar
Auburntsts Auburntsts is offline

Join Date: Jan 2005
Location: Dumfries, VA
Posts: 2,590
Default

Quote:
Originally Posted by Carl Froehlich View Post
Iíve seen this on a few RV-10 and it just scares me to think of the owner or some kid bending down under the tail and leaving an eyeball on one of these antenna rods.

I know - Iím just a worry wart.

l
It's a non-issue IMO. I won't say the risk is zero, but it's pretty low.
__________________
Todd Stovall
PP ASEL-IA
RV-10 N728TT - Flying!
WAR EAGLE!
Reply With Quote
  #8
Old 01-18-2018, 07:58 AM
Kiwi flyer Kiwi flyer is offline

Join Date: Jul 2017
Location: Pell city, al
Posts: 15
Default

Vic what brand did u use, any special mods needed to secure? . Thx Pete
Reply With Quote
  #9
Old 01-18-2018, 08:09 AM
Auburntsts's Avatar
Auburntsts Auburntsts is offline

Join Date: Jan 2005
Location: Dumfries, VA
Posts: 2,590
Default

Quote:
Originally Posted by Kiwi flyer View Post
Vic what brand did u use, any special mods needed to secure? . Thx Pete
As a data point, I have a RAMI AV-12L and I put in a doubler that is tied into the structure -- probably overkill but typical of an early build decision made years prior to first flight.



__________________
Todd Stovall
PP ASEL-IA
RV-10 N728TT - Flying!
WAR EAGLE!
Reply With Quote
  #10
Old 01-18-2018, 09:27 AM
leok leok is offline

Join Date: Apr 2013
Location: Clarkston, MI
Posts: 209
Default

Quote:
Originally Posted by Carl Froehlich View Post

Considering my homemade wingtip VOR antenna picks up VORs at 100+nmi and LOC/IOLS way beyond practical range, I can think of no reason to have any VOR antenna out in the breeze. Overlay that with the other practical aspect of five years of IFR cross country flying in the RV-10 and never using a VOR - other than tuning in the next one down the track ďjust in caseĒ.

Carl
Carl, I have an Archer wingtip VOR antenna planed for installation. DO you know if that will give reasonable performance for GS and ILS or will I need an additional/alternate antenna?
__________________
Building my RV-10 since Oct 5th 2014
Flying .. once I figure out how to pay for everything
http://www.mykitlog.com/leok
RV Hotel
Dues paid 2018
Reply With Quote
